Perfect for engraving, marking, cutting

The working area of the laser plotter is 700x500 mm.

The price of the laser plotter includes, among others: red dot, honeycomb overlay, exhaust extraction, waste drawer, integrated compressor, fan and cooling that can be started up for operation.

VAT included
€4,871.53
The price has not changed
There are not enough products in stock


  • CE
  • Instrukcja
    po polsku
  • Serwis
  • Gwarancja
    12/24
    miesięcy
  • Dostawa
    100,00 PLN

CO2 ULTRAFAST LASERS

The latest series of high-speed lasers for cutting and engraving. It saves your time and increases your competitiveness.

Fast ultrafast lasers are a guarantee of your success!

  1. Up to 200% faster compared to standard models on the market
  2. Innovative drive system guarantees much higher precision, especially for small, complex details
  3. Only with us selected the highest quality components of the best, proven producers
  4. Guaranteed original RECI tubes

LASER CUTTING PROCESS

Laser cutting is a modern and widely used technique of material processing. The cutting tool in this technique is a high energy density laser beam that cuts through the material. Laser cutting is suitable for the processing of metal, non-metal and composite materials. It is therefore quite popular.

The course of the laser cutting process

The laser cutting process is based on the effect of the laser beam at its focal point, where the beam artifact density and its power are the highest, causing rapid melting, evaporation, ablation and heating of the cut material to the ignition temperature. The place of the beam incident on the material is washed with a fast flowing gas which, while flowing along the beam incidence axis, removes the molten material. Laser cutting is one of the techniques of hot processing of materials.

LASER POWER 80 W (Reci W1 tube) (option: 90W, 130W, 160W, 180W)
CUTTING AREA 700x500 mm
DIMENSIONS 1250x870x900 mm
WEIGHT 205 kg
POSITIONING ACCURACY ± 0.05 mm
VOLTAGE 230V
POWER 800W
WORKING TEMPERATURE 0-45 ℃
HUMIDITY DURING WORK 5-95%
OPERATING SYSTEM Windows 95, 98, 2000, XP, Vista, 7, 8, 10 (32/64 bit)
INPUT FILE FORMATS PLT, AI, DST, DXF, BMP
COMPATIBLE SOFTWARE CorelDraw AutoCAD Photoshop
DRIVE TYPE Stepper motors
HEAD COOLING Water
MATERIAL COOLING air, gas

U.S II-VI optical lenses

American optics from American Photonics. Proven 14% improvement in transmission compared to other optics. High-strength gold-plated lenses and aspherical focusing lenses made by II-VI, USA.

High sharpness, high transmittance. The lenses can not only ensure the quality of the device, but also make the optical system work for a long time with high efficiency and low cost.

Platform for cutting and engraving

Comes with a honeycomb table.

High efficiency air filters

  • The environmentally friendly and pollution-free laser can be used directly indoors.
  • Tertiary filtration
  • Filter large particles into bags.
  • HEPA filtration greater than 0.03um particles.
  • Activated Carbon Adsorption System

Usage

Wood, organic glass, plastic, clothing, paper, leather, rubber and other non-metallic materials.
