CK7150 CNC Lathe
-
Instrukcja
po polsku - Serwis
-
Gwarancja
12/24
miesięcy -
Dostawa
Gratis
Technical data
Bed type |
Inclined 45° |
Guide type |
HIWIN linear guides |
Swing over bed |
ø 450 mm |
Swing over cross slide |
ø 170 mm |
Maximum working length |
500 mm |
Chuck diameter |
ø 200 mm |
X/Z axes speed |
240/400 mm |
Maximum spindle speed |
3500 rpm |
Spindle tip |
A2-5 |
Spindle bore |
ø 55 mm |
Maximum bar diameter |
ø 45 mm |
Spindle motor power |
7.5 kW |
X/Z axes torque |
7.5/7.5 Nm |
X/Z repeatability |
±0.003 mm |
Tool chuck |
8-position electrical tool chuck |
Tool shank diameter |
25×25 mm |
Tailstock spindle diameter |
ø 70 mm |
Tailstock spindle feed |
80 mm |
Tailstock spindle taper |
MT5 |
Tailstock feed |
200 mm |
Weight |
3125 kg |
Dimensions |
2500×1800×1700 mm |
Equipment
- SIEMENS 808D control system
- 3-jaw hydraulic chuck
- shavings transporter
- 8-position turret head
- set of soft jaws
- hydraulic tailstock
- cooling system
- automatic gear and guide lubrication system
- 24V halogen lighting
- Polish and English manuals
- EC declaration
